Description
DA1 Drives
Features
- High overload capability: 150% for 60 sec, 200% for 4 sec
- Integrated Modbus? RTU and CANopen
- Standard IP20 protection Integrated PID controller
- V/Hz, sensorless vector (SLV) and closed-loop vector (CLV) control
On-board I/O:
- 5 inputs (3 DI and 2 DI/AI)
- 2 outputs (2 AO/DO)
- 2 relay outputs
- Plug-in modules to expand I/O
- Optional high protection degree (IP66)
- Higher ambient temperature: +50 °C
- Safe torque off (STO) function
- Standard conformal-coated boards
- Contactor style wiring
Optional communication cards integrated in the drive:
- EtherNet I/P
- DeviceNet
- PROFIBUS? DP
- PROFINET
- Modbus TCP
- BACnet
- EtherCAT
Benefits:
- Easy menu navigation
- Ease of control wiring—detachable terminal pad
- Lean connectivity through use of SmartWire-DT
- Standard RFI filter and brake chopper circuit
- PC tool for easy configuration
- Unique functional block PLC programming capability
- Works with permanent magnet motor
- Product range 1–3 hp at 230 V (single-phase in and three-phase out)
- 1–7.5 hp at 230 V (three-phase in and three-phase out)
- 1–15 hp at 480 V (three-phase in and three-phase out)
- 1–20 hp at 600 V (three-phase in and three-phase out)
Datasheet:
