120W (24V DC) 120-240 V AC / 220 V DC – Compact

Type 78.1B Switch mode power supply with 24 V DC, 110 W output, compact in size. Equipped with an electrical system with safe separation (SELV according to EN 60950), as well as low consumption in stand-by.

Features include:

• High efficiency (up to 93%)
• Low consumption in stand-by (less than 1 W)
• LLC
• Short circuit protection: Hiccup mode (automatic reset)
• Input fuse: Easily replaceable, with spare immediately to hand
• Overvoltage protection: Varistor
• Compliant with EN 60950-1 and 61204-3
• Parallel connection for higher load current with OR diode)
• Dual polarity and serial connection possible
• 35 mm rail (EN 60715) mounting

Data Sheet
